What This Product Does
TP-LINK’s 300Mbps Mini Wireless N USB Adapter TL-WN823N is designed to connect your laptop or desktop to a wireless network and enjoy high speed wireless performance. The fingertip design makes the adapter convenient and easy to carry around. What’s more, the TL-WN823N features SoftAP Mode, one-button security setup, easy-to-use configuration software, making it a great choice for enjoying fast wireless network.
300Mbps Wireless N Speed – Extend Wireless Coverage
With wireless speeds of up to 300Mbps and advanced MIMO technology, the TL-WN823N provides you with a fast, reliable wireless connection for lag-free online gaming and video streaming. Better still, TL-WN823N achieves the best performance with wireless N devices, but also works seamlessly with existing IEEE 802.11b/g networks
Easy to Install
A friendly user interface utility on a CD for simple installation
Soft AP
Easily establish a high speeds Wi-Fi hotspot with just a few clicks
WPS
Easy wireless security encryption at a push of the WPS button
Specifications
| Connectivity technology | Wired |
| Host interface | USB |
| Interface | WLAN |
| Maximum data transfer rate | 300 Mbit/s |
| Networking standards | IEEE 802.11b,IEEE 802.11g,IEEE 802.11n |
| Wi-Fi | Y |
| Wi-Fi band | Single-band (2.4 GHz) |
| Frequency range | 2.4 - 2.4835 GHz |
| Top Wi-Fi standard | Wi-Fi 4 (802.11n) |
| Wi-Fi standards | 802.11b,802.11g,Wi-Fi 4 (802.11n) |
| WLAN data transfer rates supported | 11,54,300 Mbit/s |
| Modulation | 16-QAM,64-QAM,CCK,DBPSK,DQPSK,OFDM |
| Security algorithms | 64-bit WEP,128-bit WEP,WPA,WPA-PSK,WPA2,WPA2-PSK |
| Wake-on-LAN ready | Y |
| Component for | PC/notebook |
| Product colour | Black |
| Internal | N |
| Plug and Play | Y |
| LED indicators | Status |
| USB powered | Y |
| Compatible operating systems | Windows XP (32/64-bit) Windows Vista (32/64-bit) Windows 7 (32/64-bit) |
| Windows operating systems supported | Y |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 90% |
| Width | 39 mm |
| Depth | 18.4 mm |
| Height | 7.87 mm |
| Quick installation guide | Y |
