No Configuration Needed Simply Plug and Play!
With an integrated 4G LTE modem and a built-in SIM card slot, all you need to do is insert a SIM card and turn on the TL-MR6400. Enjoying fast, stable Wi-Fi on a 4G LTE network has never been easier.
Share Your 4G LTE Network
Take full of advantage of your cutting-edge 4G LTE network, which can achieve download speeds of up to 150 Mbps. The TL-MR6400 shares your 4G LTE network with multiple Wi-Fi devices, so you can enjoy uninterrupted HD movies, rapid file downloads, and smooth video chats. It is also fully compatible with FDD-LTE and TDD-LTE, which are supported by most operators around the world.
Wi-Fi Where You Need It
The TL-MR6400 offers unmatched convenience and versatility. Whether you’re at hom or working in a remote location, the TL-MR6400 is the perfect solution. Just plug it in to boost on-site productivity and stay connected in a diverse range of environments.
From the exhibition center to the RV, the TL-MR6400 always has you covered.
Internet Access for up to 32 Devices simultaneously
The TL-MR6400 can easily share a 3G/4G connection with up to 32 wireless devices, such as tablets, laptops and mobile phones at the same time. The LAN ports are also ready to provide internet for wired devices like desktop computers.
Easy Management
Set up the TL-MR6400 in minutes thanks to its intuitive web interface and the powerful Tether app. Manage network settings from any Android or iOS device. Control your home network anytime and anywhere.
Specifications
| Ethernet WAN | Y |
| DSL WAN | N |
| SIM card slot | Y |
| 3G/4G USB modem compatibility | N |
| WAN connection type | RJ-45 |
| Wi-Fi band | Single-band (2.4 GHz) |
| Top Wi-Fi standard | Wi-Fi 4 (802.11n) |
| WLAN data transfer rate (max) | 300 Mbit/s |
| Wi-Fi standards | 802.11b,802.11g,Wi-Fi 4 (802.11n) |
| Ethernet LAN | Y |
| Ethernet LAN interface type | Fast Ethernet |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Cabling technology | 10/100Base-T(X) |
| Networking standards | IEEE 802.11b,IEEE 802.11g,IEEE 802.11n,IEEE 802.3 |
| Port forwarding | Y |
| 3G | Y |
| Mobile network generation | 4G |
| 4G | Y |
| 3G standards | HSPA+,UMTS |
| 4G standard | LTE |
| UMTS bands supported | 1900,2100 MHz |
| 4G bands supported | 800,900,1800,1900,2100,2600 MHz |
| Ethernet LAN (RJ-45) ports | 4 |
| USB port | N |
| Memory card slot(s) | N |
| DC-in jack | Y |
| Web-based management | Y |
| Quality of Service (QoS) support | Y |
| Reset button | Y |
| WPS push button | Y |
| Security algorithms | 64-bit WEP,128-bit WEP,WPA,WPA-PSK,WPA2,WPA2-PSK |
| Firewall | Y |
| Stateful Packet Inspection (SPI) | Y |
| DoS attack prevention | Y |
| Filtering | Y |
| MAC address filtering | Y |
| IP address filtering | Y |
| DMZ support | Y |
| DHCP client | Y |
| DHCP server | Y |
| Universal Plug and Play (UPnP) | Y |
| Supported network protocols | IPv4, IPv6 |
| Product colour | Black |
| LED indicators | LAN, Power, WLAN |
| On/off switch | Y |
| Product type | Tabletop router |
| Antenna type | External |
| Antennas quantity | 2 |
| Detachable antenna(s) | Y |
| Certification | CE, RoHS |
| Power source type | DC |
| Output voltage | 9 V |
| Output current | 0.85 A |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 90% |
| Windows operating systems supported | Y |
| Linux operating systems supported | Y |
| Mac operating systems supported | Y |
| Mac compatibility | Y |
| Width | 202 mm |
| Depth | 163 mm |
| Height | 33.6 mm |
| Cables included | LAN (RJ-45) |
| AC adapter included | Y |
| Manual | Y |
| Quick installation guide | Y |
| Quick start guide | Y |
