Designed for Data Caching
Optimized for cloud storage architectures, the Intel SSD DC P4600 Series significantly increases server agility and utilization, while also accelerating applications, across a wide range of cloud workloads.
Optimized for Storage Efficiency
Intel® 3D NAND SSDs for the data center reduce the need for specialized servers, increase technician efficiency and lessen Opex and Capex, enabling organizations to squeeze every last bit and byte from the data center.
Outstanding Quality and Reliability
With industry-leading quality and reliability, you can be confident your drives are available and your data is protected. Support for data-at-rest encryption minimizes the likelihood of data breaches, while industry-leading end-to-end data protection reduces the chance of silent data errors.
Advanced Manageability and Serviceability
Built with advanced manageability features such as NVMe-MI, the Intel SSD DC P4600 Series allows you to remotely monitor, manage and remediate across more device states and streamline essential services.B 2.5IN PCIE 3D1 TLC.
Specifications
| NAND flash type | TLC (Triple Level Cell) |
| NVMe version | 1.2 |
| Security algorithms | 256-bit AES |
| SSD form factor | 2.5" |
| SSD capacity | 1600 GB |
| Interface | PCI Express 3.1 |
| Memory type | 3D TLC |
| NVMe | Y |
| Component for | Server/workstation |
| Hardware encryption | Y |
| Read speed | 3290 MB/s |
| Write speed | 1390 MB/s |
| Random read (100% span) | 587000 IOPS |
| Random write (100% span) | 184000 IOPS |
| Read latency | 79 µs |
| Write latency | 34 µs |
| PCI Express interface data lanes | x4 |
| End-to-End Data Protection | Y |
| Enhanced Power Loss Data Protection technology | Y |
| SSD temperature monitoring | Y |
| Uncorrectable Bit Error Rate (UBER) | < 1 per 10^17 bits read |
| Mean time between failures (MTBF) | 2000000 h |
| TBW rating | 8520 |
| Market segment | Server |
| SSD usage tag | Data center |
| SSD ARK ID | 97005 |
| Compatible products | Intel Server System R1208WFTYS, R2208WF0ZS, R2208WFTZS, R2224WFTZS, R2308WFTZS, R2312WF0NP, R2312WFTZS |
| Power consumption (read) | 8.46 W |
| Power consumption (write) | 13.87 W |
| Power consumption (idle) | 5 W |
| Intel High Endurance Technology (HET) | Y |
| Intel® Rapid Start Technology | N |
| Intel® Remote Secure Erase | N |
| Intel® Smart Response Technology | N |
| Intel Smart Response Technology version | 0.00 |
| Operating temperature (T-T) | 0 - 35 °C |
| Operating vibration | 2.17 G |
| Non-operating vibration | 3.13 G |
| Operating shock | 1000 G |
| Non-operating shock | 1000 G |
| Height | 15 mm |
| Weight | 134 g |
| Product colour | Silver |
| Cooling type | Heatsink |
| Drive capacity | 1600 GB |
| Launch date | Q2'17 |
| Product brief URL | http://www.intel.com/content/www/us/en/solid-state-drives/ssd-dc-p4600-brief.html |
| SSD endurance rating | 8.99 PBW |
| SSD hardware encryption | AES 256 bit |
| SSD power consumption (active) | Sequential Avg. 14.2W (Write), 9W (Read) |
| SSD power consumption (idle) | <5 W |
| SSD shock | 1000 G/0.5 msec |
| SSD weight | 131 g |
| Sequential reading | 3200 MB/s |
| Sequential writing speed | 1325 MB/s |
| Status | Launched |
| Last change | 63903513 |
| Intel Rapid Start Technology version | 0.00 |
| Remote Secure Erase (RSE) technology version | 0.00 |
| Product family | Data center SSD |
| Product series | Intel® SSD DC P4600 Series |
| Product codename | Cliffdale |
