The compact, ready-to-stream ASUS TUF GAMING CAPTURE BOX-4KRPO delivers incredible 4K60 video with near-zero latency to captivate fans and followers.
TUF GAMING CAPTURE BOX-4KPRO
Whether you want to broadcast to your followers while playing on a console or PC, ASUS TUF GAMING CAPTURE BOX-4KPRO lets you unleash top-notch gaming streams that’ll make the crowd to wild.
Capture Every Detail of the Action
ASUS TUF GAMING CAPTURE BOX-4KPRO supports up to 4K144 HDR passthrough via HDMI 2.1 ports and keeps your gameplay smooth by offloading up to 4K60 video to your external workstation or laptop via a USB 3.2 Gen 2 connection. Get ready to amaze your followers with livestreams in mind-blowing quality.
Streaming with Squad or Solo
For streamlined capturing of console parties or live solo commentary, a headset and controller can be connected to ASUS TUF GAMING CAPTURE BOX-4KPRO via two 3.5 mm jacks. The headset connection seamlessly transmits audio to party members and allows the audience to listen in on all the action.
Certified for OBSâ„¢
Backed by OBS Studioâ„¢ certification, ASUS TUF GAMING CAPTUE BOX-4KPRO delivers masterful video content tailored for your favorite streaming platform.
On-board Scaling Supported
With an onboard scaler, TUF GAMING CAPTURE BOX-4KPRO can automatically sync up streaming resolution with input resolution, eliminating the need to make extra adjustments and making setup easier and quicker.
VRR Passthrough For Fluid Gameplay
VRR (variable refresh rate) passthrough is an additional perk of the ASUS TUF GAMING CAPTURE BOX-4KPRO, enabling smooth visuals by synchronizing the refresh rate of your VRR-compatible display with the frame rate of your console or PC.
*VRR passthrough requires connected devices to support HDMI 2.1; check with your device manufacturers to confirm compatibility.
Compact, Ready-to-Go Design
Inside and out, ASUS TUF GAMING CAPTURE BOX-4KPRO is crafted for hassle-free operation. Its half-palm-sized aluminum chassis reduces desktop clutter and silently boosts reliability by dissipating heat generated by internal components. And USB class video support allows PC or laptop hookup without requiring dedicated drivers, for rapid deployment anytime, anywhere.
ASUS Video Capture Console
A software dashboard from Asus, the Video Capture Console not only lets you customize the lighting effects of the TUF GAMING CAPTURE BOX’s ARGB element and enables full audio control from your PC or console, it also allows you to setup the recording and livestream functions.
Customizable Lighting Effects
The front of the ASUS TUF GAMING CAPTUE BOX-4KPRO is illuminated by an ARGB lighting strip that conveniently indicates functional status.​
Get Ready to Capture and Conquer
Gaming device, streaming PC, controller, and headset – just hook up each to immediately start streaming the action to your followers!
Specifications
| Product colour | Black |
| Internal | No |
| Host interface | USB 3.2 Gen 2 (3.1 Gen 2) |
| Video capture resolution (max) | 3840 x 2160 pixels |
| Memory card slot(s) | No |
| High Dynamic Range (HDR) supported | Yes |
| Maximum frame rate | 120 fps |
| USB port | Yes |
| USB connector type | USB Type-C |
| USB version | 3.2 Gen 2 (3.1 Gen 2) |
| HDMI ports quantity | 2 |
| HDMI in | 1 |
| Number of HDMI outputs | 1 |
| HDMI version | 2.1 |
| Headphone outputs | 2 |
| Minimum system requirements | Intel® Core™ i5-6XXX or above Recommended：Intel® Core™ i7-6XXX or above AMD® Ryzen™ 5 1XXX or above Recommended：AMD® RYZEN™ 7 1XXX or above Intel® Core™ i5-6XXX or above AMD® Ryzen™ 5 1XXX or above 8GB or above (Dual-channel*) Recommended：16GB or above (Dual-channel) *You have to set your memory on dual channel mode in your computer system. NVIDIA® GeForce® GTX1060 or above AMD® Radeon™ HD7870 or above *If recording a 4K, HDR, high frame rate etc, it needs a NVIDIA VGA card. NVIDIA® GeForce® GTX1060 or above *If recording a 4K, HDR, high frame rate etc, it needs a NVIDIA VGA card. Requires USB 3 |
| Minimum RAM | 8192 MB |
| Width | 105 mm |
| Depth | 80 mm |
| Height | 21 mm |
| Weight | 161 g |
| Package weight | 482 g |
| Package height | 61 mm |
| Package width | 168 mm |
| Package depth | 139 mm |
| Package type | Box |
| Quantity | 1 |
