Balances expandability and performance
Flexible two-socket tower server for enterprise workloads outside of the traditional data center.
Specifications
| Processor manufacturer | Intel |
| Processor family | Intel Xeon Silver |
| Processor generation | 3rd Generation Intel® Xeon® Scalable |
| Processor model | 4309Y |
| Processor frequency | 2.8 GHz |
| Processor boost frequency | 3.6 GHz |
| Efficient-core base frequency | 0.0028 GHz |
| Performance-core base frequency | 2.8 GHz |
| Processor cores | 8 |
| Processor cache | 12 MB |
| Number of processors installed | 1 |
| Maximum internal memory supported by processor | 32 GB |
| Internal memory | 16 GB |
| Internal memory type | DDR4-SDRAM |
| Buffered memory type | Registered (buffered) |
| Memory ranking | 2 |
| Memory slots | 16x DIMM |
| Memory layout (slots x size) | 1 x 16 GB |
| Memory data transfer rate | 3200 MT/s |
| Maximum internal memory | 64 GB |
| Total storage capacity | 480 GB |
| Number of SSDs installed | 1 |
| SSD capacity | 480 GB |
| SSD interface | SATA III |
| SSD size | 2.5" |
| Supported SSD sizes | 3.5" |
| Number of SSDs supported | 8 |
| RAID support | Yes |
| Supported RAID controllers | PERC H755 |
| Hot-Plug support | Yes |
| Optical drive type | No |
| Internal drive bays | 8 |
| Supported storage drive interfaces | SAS, Serial ATA |
| Drive writes per day (DWPD) | 1 |
| Storage drive adapter included | Yes |
| Storage drive adapter type | 2.5" - 3.5" |
| On-board graphics card | No |
| On-board graphics card model | Not available |
| Ethernet LAN | Yes |
| Cabling technology | 10/100/1000Base-T(X) |
| Ethernet interface type | Gigabit Ethernet |
| Ethernet LAN (RJ-45) ports | 2 |
| USB 2.0 ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| VGA (D-Sub) ports quantity | 1 |
| Serial ports quantity | 1 |
| Power cables quantity | 1 |
| Chassis type | Tower |
| Product colour | Black |
| Bezel | Yes |
| Remote administration | iDRAC9, Enterprise 15G |
| Operating system installed | No |
| Compatible operating systems | Canonical Ubuntu Server LTS ● Citrix Hypervisor Microsoft Windows Server with Hyper-V Red Hat Enterprise Linux SUSE Linux Enterprise Server VMware ESXi |
| Redundant power supply (RPS) support | No |
| Power supply | 700 W |
| Number of main power supplies | 1 |
| Power supply input voltage | 200 - 240 V |
| Power cable length | 2 m |
| Power cable connector 1 | C13 coupler |
| Power cable current | 10 A |
| Operating temperature (T-T) | 10 - 35 °C |
| Storage temperature (T-T) | -40 - 65 °C |
| Storage relative humidity (H-H) | 5 - 95% |
| Operating altitude | 0 - 3048 m |
| Non-operating altitude | 0 - 12000 m |
| Total carbon footprint | 9090 kg of CO2e |
| Total carbon emissions (Standard deviation) | 4620 kg of CO2e |
| Carbon emissions (Manufacturing) | 1095 kg of CO2e |
| Carbon emissions (Logistics) | 565 kg of CO2e |
| Carbon emissions (Energy Usage) | 7390 kg of CO2e |
| Carbon emissions (End-of-Life) | 47 kg of CO2e |
| Total carbon emissions (w/o Use phase) | 1707 kg of CO2e |
| PAIA version | 1.3.2, 2022 |
| Width | 200 mm |
| Depth | 680.5 mm |
| Height | 459 mm |
| Data transfer rate | 6 Gbit/s |
| Bytes per sector | 512 |
